AC Current Transducer

Overview: The AC Current Transducer (Model No. 26-25-118) is designed to convert AC current measurements into a 4-20mA output signal. Ideal for use in the Generator Unit Control Panel (GUCP-1) of Ansaldo G.T. generators, this transducer ensures precise monitoring of AC current in power generation systems. With input ranges from 0-1A AC and a highly accurate 0.5% accuracy class, the transducer offers real-time performance feedback for generator control systems. The device is built to withstand harsh industrial environments and meets international standards such as IEC 60688.

Material Number: 26-25-118
Product Name: AC Current Transducer
Type: AC Current Transducer
Range: Input: 0-1A AC, Output: 4-20mA DC
Power Source: 110VAC, 50Hz
Application: Generator Unit Control Panel (GUCP-1) of Ansaldo G.T. Generator

Applications: The AC Current Transducer is specifically designed for use in the Generator Unit Control Panel (GUCP-1) of Ansaldo G.T. driven generators. It is used for accurate current measurement and signal transmission in the control systems of generator units. The transducer plays a critical role in maintaining the stability and efficiency of power generation equipment by converting AC current inputs into a standardized 4-20mA output signal, allowing integration with monitoring and control systems.

Technical Specifications:

• Input Range: 0-1A AC
• Output Range: 4-20mA
• Number of CT Inputs: 01
• CT Input: 500/1A AC
• Auxiliary Supply: 110VAC/50Hz
• Power Supply: 110VAC/50Hz
• Accuracy Class: 0.5
• Ripple (Peak-Peak): < 1%
• Response Time: < 0.15 seconds
• Variation: < 1 PPM/Ohm
• Output Load: 0-750 Ohm
• Protection: Short-circuit and open-circuit
• Mounting: DIN Rail Mount
• Compliance: IEC 60688
• Manufacturer Part Number: CELSA: CINV/1

Important Note: The AC Current Transducer is essential for accurate monitoring of AC current in generator units. It is built to withstand industrial environments and supports reliable data transmission to control and protection systems.
